Type E EZ-Stop Baywindow Bus Disk Brake Kit 1968-1970

  • $545.00

Only -54 left!

FINALLY...an affordable AND simple 1968-1970 bus disk brake kit that FITS STOCK 14" BAYWINDOW BUS WHEELS!!  This kit is almost identical to the split bus kit, but it uses a different wheel seal

We designed this kit to be an easy, bolt-on install with all of the required bits and pieces to make the install a breeze.

Rather than building a kit based off custom-made or fancy race car parts, we went the other way and built our kit using super-common, easy-to-get parts.  Willwood and similar "race car" calipers do not have dust seals, so they have a limited lifespan before the pistons start to wear out the bores requiring replacement.

The rotors, calipers and brake pads for this kit are used on millions of American cars, and the parts are readily available at nearly every auto parts store across the USA.  They are built to last for 100,000's of miles in terrible conditions.  If you are 1000 miles from home, and you need a replacement rotor or pads, there is no need to wait a week or more for custom-made replacement parts.  Just swing by your local NAPA with the part numbers provided in the kit.

The single best way to improve braking performance doesn't come from adding more pistons to the calipers, it comes from increasing the rotor's outside diameter.  This increases the effective leverage.  Some other kits use a 9.25" rotor that is custom machined even smaller to fit inside a 14" bus wheel.  Or a thin 3/8" thick rotor that is only available from ONE company.  Some of these rotors are over $150 EACH when they need to be replaced, and hopefully they are still available when you need one.  The rotors to use with this kit are large 10.5" diameter, 1" thick vented style, 100% off-the-shelf rotors that need NO custom machine work.  They also come with the bearing races pressed in.

The calipers are used on countless GM mid-size cars that are heavier than a VW bus.  These calipers have a much larger pads surface area than a Willwood caliper, and there are lots of different brands, grads, and type of pads available.  The piston area of these calipers is very similar to the piston area of a Willwood, so the pedal feel, and clamping force is very similar between the two.

The caliper brackets are made from 3/8" laser cut steel, the adapters to the stock  5x205mm bolt pattern are made from 1/2" laser cut steel, then machined on CNC equipment.  We add custom MADE IN THE USA press-in 14mm wheel studs, and include lug nuts to fit stock VW steel wheels.

High quality Timken or National bearings, new conversion rubber brake hoses, lug nuts, wheel seals, and new billet anodized dust caps are all included in the kit.

Not included in the kit are the calipers, rotors, and brake pads.  We have done this for a few good reasons.  Included with the kit are all the necessary part numbers and applications that will cross-reference at any good auto parts store.  Shipping heavy rotors, calipers and pads is very expensive.  We figure since you own a VW you are already familiar with your local auto parts store.  Take the list of part numbers into your local store and pick up the parts yourself to save the shipping.  For you folks who want drilled or slotted rotors, those are available from other on-line retailers as well. Some people/shops also have connections and get good parts store discounts, saving themselves even more.



With stock 14" steel wheels, this kit will only add about 3/8" to each side, or 3/4" to the overall track width.  Most aftermarket 5x205 wheels can be run without the extra 3/8" outer spacer, making the disk kit almost the same as stock width.

This kit will work with the stock master cylinder, but you will need to remove the residual pressure valve from the front line in your system.  This is very easy to do, and there are pictures at the end of the instructions linked below.

Click here for install instructions and part numbers for the EZ-Stop disk brake kit

The $545.00 price for the disk kit INCLUDES the shipping to anywhere in the USA including delivery to Alaska, Hawaii, Puerto Rico, Guam, or the U.S. Virgin Islands.





Click here for the 5x130 Porsche pattern EZ-Stop disk kit


We Also Recommend


Customer Reviews

Based on 1 review Write a review

Customer Reviews

Based on 3 reviews
100%
(3)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
s
steven fessenden
Awsome dusk brake conversion

I purchased this disk brake conversion for my 68 westy. I found all the parts I needed to buy on rock auto.It cost me $150 , for the rotors , calipers and pads. everthing went on easy with straight forward instructions. I emailed a question and they got back to me the same day. they perform as advertised, greatly improving the braking over the stock drums.

F
Fred Hull

Purchased the front disc kit for a '69 Bay Window. Took it to a local shop for an install - back same day 3.75 hours labor and a very happy shop owner said: "Great kit, everything was there and it went in with no problems." Drove it home and for the first time in years it stops quickly and in a straight line! Highly recommended - including labor the cost was less than the other kits alone and I now have reliable easy to fix brakes with way more stopping power.

R
Robert Charles
Early bay window disc brake kit

I have installed several disc brake kits I personally have this kit on my split buses and bay window buses. Kit is very easy to install and quality of the brackets and spacers is very good. I installed a popular name brand kit that is none vented. Disc brake kit on a 68 westy camper Customer complains of loss of brake pedal on long grades due to rotor overheating and boiling brake fluid. Customer is now going to this kit to eliminate this problem Theses guys are quick to answer any questions and offfer any help.
